Backed by our wide distribution channels, we supply a broad gamut of gas handling equipment that ensure safe and proper handling of cylinder gases. Each equipment offered by us is thoroughly tested at manufacturer’s site and further, is inspected by our quality supervisors assuring trouble-free service. Available in variety of industry specific configurations, these are widely used across cement, chemical , medical, food, metal etc.,industries. The array of gas handling equipment offered by us are:

Pressure Gauges
We also provide dial type digital pressure gauges in various sizes and ranges. Sourced from trusted vendors across the country, these are calibrated with master gauges as well as are equipped with traceable NPL. These are widely used across industries like chemicals & fertilizers plants, refineries, thermal power stations etc. The pressure gauges can be availed at best industry prices.

Features:

• Diaphragm operated
• Measure positive, negative, or differential pressure
• Cast aluminum black IP – 55 weather proof case
• Low maintenance cost
• Brass / SS Movement
• Direct, Surface & Panel mounting

Gas Cylinder Manifolds
Why a Gas Distribution System?

If you think about it, most of the gases are toxic, flammable, corrosive, or often a combination of these. Other gases constitute a different hazard-such as asphyxiation, anesthesia or, simply, pressure. For some customer installations, a simple pressure regulator or control valve will not suffice, for example:

• Where the gas, for physical considerations of space or location, must be stored in an area remote from point of use.
• Where two or more cylinders are coupled together for high flow-rates.
• Where a regular purge cycle is required between gas uses or at cylinder change-over.
• Where safety considerations with a toxic or flammable gas require that equipment and/or pipelines containing that gas should be totally isolated from the working environment.
• Where gas flow, pressure or temperature requirements are such that a very sophisticated means of gas control is required, especially in bulk gas installations.
• In this there is clearly a need for a specialist designed Gas Distribution System.

Gas Accessories
Supported by wide distribution channel, we offer wide range of industrial gas accessories such as fine control needle valves, S.S. 316 gas sampling valves, flowmeters, tubings, ampules breakers, fittings, couplings, etc. that are procured from reliable vendors. The manufacturers make sure that these are manufactured from quality iron, aluminum, steel, brass castings and forgings as well as conform to the ISO standards.

Features:

• Manufactured using high quality stainless steel or brass
• Used across industries like metal, medical, chemical, food, pharma etc.
• Wide range of equipment such as valves, flowmeters, tubings etc.
• Variety of valves like flanged, socket weld, screwed etc., are offered
• Fittings include PVC fittings, polypropylene fittings, steel fittings, malleable iron fittings
• Size: 15 mm to 250 mm

Gas Mixing Systems and Gas Blending Systems
The Gas blending system can mix and blend two or more gases with each other at a predefined ratio. It can be used for blending or to dilute gases to generate precise calibration gas standards, production gas mixtures or to create gaseous atmosphere. The gases can be mixed in a ratio of 1:1 upto 1: 1000.

The system automatically dilutes high concentration certified gas cylinder to a wide range of of concentrations from high percentage to low parts per million.

The system is operated by controls set at front panel. After entering required concentration, the system automatically mixes gases connected to the ports to generate required mixture.

Gas Mixing System
The gas mixer precisely dilutes and blends high concentration certified gas cylinders to generate precise gas calibration standards, create gaseous atmospheres, or produce gas mixes for analytical research and process gas mixture purpose.

The mixer can produce complex mixes containing upto seven individual gases in a balance gas. The mixer produces gases from a percentage level to parts per million level for single or multipoint calibration.

The mixer consists of control instrumentation and mixing zone. Commands are entered from front panel. Optional RS232 control with computer controlled command mode is also available.

Features:

• Reduced cost of Gas Standards: Calibration gases is a costly affair. The mixer reduces / stops costly expense of calibration gases needed for calibration of instruments. Also reduced inventory of gas cylinders due to broad range of dilution ratios. It enhances profitability in process industries due to eliminating costly process gas mixtures. The mixer can be used for online gas mixing.
• Wide Dilution Ratio: Broad range of dilution ratios (1:1 upto 10000:1) allows user to significantly reduce the number of gas cylinders needed to perform compliance tests.
• State of the Art Software: Automatic calculation of dilution and span gas flows based on the concentration commanded by the user eliminates the need for manual computation allows rapid transition from point to point and scale to scale.
• The mass flow controllers are calibrated to using a NIST traceable primary standard.

Specifications:
Accuracy: From 10 to 100% of full scale: ? 1% for concentration and flow and repeatability

• Inlet Port ¼” OD swagelok
• Outlet Ports ¼” OD swagelok
• Operating pressure at inlets: 25 psig
• Tubing Electro polished SS316
• MFC SS316
• Seals Viton (Optional – Karlez, Buna –N, Neoprene)
• Operating Temperature 0 – 500 C
• Data Output / Input RS232 serial data

Gas Changeover Module
This unique equipment is designed for application where many gas lines are to be cross linked to be cross linked to an instrument & carrier gas is changed from one to another frequently.

This equipment is suitable for varying pressures, with all wetted parts in S.S.304 / 316, is available ready for a wall mounted installation




High Pressure Cylinder Changeover Manifold
These are designed for high pressure application and to changeover the gas supply from a near empty cylinder to full cylinder quickly.

The standard version is for two cylinders, is made of S.S.316 and is compatible to most of the gases and flexible tail pipes.

Manifold for more number of cylinder are also available
